The AI Caching Playbook, Part 2: Agentic AI Caching

A production agent shouldn't repeatedly perform work it has already completed.

This is Part 2 of the AI Caching Playbook. Part 1 covered the 10 core caches in the AI stack. This part goes deeper into agents: tools, workflows, state and MCP.

Agentic AI systems are fundamentally different from simple LLM applications.

A traditional LLM application often looks like:

A RAG application adds retrieval:

An agent can be much more complicated:

And this process may involve:

• APIs
• databases
• web searches
• MCP tools
• internal services
• other agents
• LLM calls
• long-running workflows
• retries
• checkpoints
• intermediate results

Without caching, an agent can repeatedly perform the same expensive work. For example, an agent handling a customer request might:

Now imagine the agent retries because of a temporary failure. It may do all of it again:

That's unnecessary. A production-grade agent should be able to say:

"I already completed this step. I can reuse the result."

That's where agentic caching becomes important.

1. Tool result cache#

1.1 What is it?#

Tool calls are one of the biggest caching opportunities in agentic systems.

Suppose an agent has get_customer(), get_orders(), get_inventory(), get_weather(), search_web() and get_exchange_rate(). The agent might call get_customer(customer_id=123) several times during the same task. If the customer information hasn't changed, making the same API call again provides little value.

Instead:

1.2 Basic implementation#

Using Redis:

import json

import redis.asyncio as redis

redis_client = redis.Redis(host="localhost", port=6379, decode_responses=True)


async def cached_tool_call(tool_name: str, arguments: dict, tool_fn, ttl: int = 300):
    cache_key = f"tool:{tool_name}:{json.dumps(arguments, sort_keys=True)}"

    cached = await redis_client.get(cache_key)
    if cached:
        return json.loads(cached)

    result = await tool_fn(**arguments)

    await redis_client.setex(cache_key, ttl, json.dumps(result))
    return result

Usage:

customer = await cached_tool_call(
    tool_name="get_customer",
    arguments={"customer_id": "123"},
    tool_fn=get_customer,
    ttl=600,
)

1.3 Production cache key#

Don't key on the tool name alone. A tool can be called with different arguments.

Bad:

key = "get_customer"

Better: combine the tool name + arguments + tool version + tenant ID. For example:

import hashlib
import json


def tool_cache_key(tenant_id: str, tool_name: str, arguments: dict, tool_version: str):
    raw = json.dumps(
        {
            "tenant_id": tenant_id,
            "tool": tool_name,
            "arguments": arguments,
            "version": tool_version,
        },
        sort_keys=True,
    )
    return hashlib.sha256(raw.encode()).hexdigest()

2. Function call cache#

2.1 What is it?#

Tool caching and function-call caching are closely related, but function-call caching can be applied at a lower level of abstraction. Consider:

If the same function arguments produce the same result for a reasonable period, cache the function execution.

2.2 Example#

import time
from functools import wraps


def cached(ttl=300):
    cache = {}

    def decorator(fn):
        @wraps(fn)
        def wrapper(*args, **kwargs):
            key = (fn.__name__, args, tuple(sorted(kwargs.items())))
            now = time.time()

            if key in cache:
                value, timestamp = cache[key]
                if now - timestamp < ttl:
                    return value

            result = fn(*args, **kwargs)
            cache[key] = (result, now)
            return result

        return wrapper

    return decorator

Usage:

@cached(ttl=60)
def get_exchange_rate(from_currency, to_currency):
    return external_exchange_api(from_currency, to_currency)

Now get_exchange_rate("USD", "INR") doesn't necessarily hit the external API every time.

2.3 Don't cache everything#

This is critical. Consider create_payment(), delete_user(), place_order() and transfer_money().

These are side-effecting operations, and blindly caching them can be dangerous. place_order() should not be treated like a read such as get_customer().

For mutations, you usually need idempotency, which we'll cover later.

3. Agent state cache#

3.1 What is it?#

An agent isn't just producing an answer. It has state. For example:

{
  "task_id": "task_123",
  "goal": "Research company X",
  "current_step": "financial_analysis",
  "completed_steps": ["company_search", "financial_report"],
  "results": {
    "company": "...",
    "revenue": "..."
  }
}

This state allows the agent to resume execution.

3.2 With and without state#

3.3 Redis implementation#

import json


async def save_agent_state(task_id: str, state: dict, ttl: int = 3600):
    await redis_client.setex(f"agent:state:{task_id}", ttl, json.dumps(state))


async def load_agent_state(task_id: str):
    data = await redis_client.get(f"agent:state:{task_id}")

    if not data:
        return None

    return json.loads(data)

3.4 Agent loop#

state = await load_agent_state(task_id)

if not state:
    state = {"completed_steps": [], "results": {}}

if "search" not in state["completed_steps"]:
    result = await search_company()

    state["results"]["company"] = result
    state["completed_steps"].append("search")

    await save_agent_state(task_id, state)

The important part is:

Persist state after meaningful checkpoints, not only when the entire task finishes.

4. Workflow and step cache#

4.1 What is it?#

Agent workflows frequently contain deterministic steps. Consider a research agent:

1. Search company
2. Extract revenue
3. Calculate growth
4. Find competitors
5. Generate report

If step 3 has already completed successfully, don't execute it again.

4.2 Step cache architecture#

4.3 Implementation#

async def execute_step(workflow_id: str, step_name: str, input_data: dict, step_fn):
    key = make_step_key(workflow_id, step_name, input_data)

    cached = await redis_client.get(key)
    if cached:
        return json.loads(cached)

    result = await step_fn(input_data)

    await redis_client.setex(key, 3600, json.dumps(result))
    return result

4.4 Why this is powerful#

Imagine the workflow fails at step 5 and has to be retried:

This becomes extremely important for long-running agents.

5. MCP tool cache#

5.1 What is it?#

Model Context Protocol (MCP) systems introduce another caching opportunity. An agent might reach search, a database, files, a CRM and internal APIs through MCP servers. Repeated MCP calls can add unnecessary latency.

Conceptually:

5.2 Cache by tool and arguments#

def mcp_cache_key(server, tool, arguments, version):
    payload = {
        "server": server,
        "tool": tool,
        "arguments": arguments,
        "version": version,
    }
    raw = json.dumps(payload, sort_keys=True)
    return hashlib.sha256(raw.encode()).hexdigest()

Then:

async def call_mcp_tool(server, tool, arguments):
    key = mcp_cache_key(server, tool, arguments, version="v1")

    cached = await redis_client.get(f"mcp:{key}")
    if cached:
        return json.loads(cached)

    result = await actual_mcp_call(server, tool, arguments)

    await redis_client.setex(f"mcp:{key}", 300, json.dumps(result))
    return result

5.3 Be careful with MCP caching#

Not every MCP resource should be cached equally:

The cache policy belongs to the data semantics, not just the tool name.

6. MCP resource cache#

6.1 What is it?#

MCP isn't only about tools. Resources can also represent data that agents access repeatedly, for example file://company/policy.pdf, db://customers/123 or docs://product/api.

A resource cache avoids fetching the same resource again and again.

6.2 Example#

async def get_mcp_resource(resource_uri: str, fetch_fn, ttl: int = 600):
    key = "mcp:resource:" + hashlib.sha256(resource_uri.encode()).hexdigest()

    cached = await redis_client.get(key)
    if cached:
        return json.loads(cached)

    resource = await fetch_fn(resource_uri)

    await redis_client.setex(key, ttl, json.dumps(resource))
    return resource

6.3 Version-aware resources#

If resources have versions, keying on the version too is safer:

• Any resource: resource URI + resource version
• Documents: document ID + document version
• APIs: resource ID + updated_at

7. API response cache#

7.1 What is it?#

Agents frequently call external services: weather, stock prices, CRM, search, maps. External calls introduce:

• latency
• rate limits
• cost
• network failures

Caching can reduce all four.

7.2 Production implementation#

import json


async def cached_api_response(key: str, fetch_fn, ttl: int = 300):
    cache_key = f"api:{key}"

    cached = await redis_client.get(cache_key)
    if cached:
        return json.loads(cached)

    result = await fetch_fn()

    await redis_client.setex(cache_key, ttl, json.dumps(result))
    return result

Usage:

weather = await cached_api_response(
    key="weather:bengaluru",
    fetch_fn=lambda: fetch_weather("bengaluru"),
    ttl=300,
)

7.3 Stale-while-revalidate#

For some applications, you don't need perfectly fresh data. You can serve a slightly stale result while refreshing the cache in the background:

This can dramatically reduce latency.

8. Agent memory cache#

8.1 What is it?#

Agent memory can exist at multiple levels:

Not all memory needs to be fetched from a database every time.

8.2 Example#

async def get_user_memory(user_id: str):
    key = f"memory:user:{user_id}"

    cached = await redis_client.get(key)
    if cached:
        return json.loads(cached)

    memory = await database.get_user_memory(user_id)

    await redis_client.setex(key, 1800, json.dumps(memory))
    return memory

Now the agent can access frequently used memory quickly.

8.3 Memory invalidation#

Suppose the user changes their preferred language from English to Tamil. Your memory cache must be invalidated:

await redis_client.delete(f"memory:user:{user_id}")

Otherwise the agent may keep using stale information.

9. Planning and reasoning cache#

9.1 What is it?#

This is one of the more advanced forms of agent caching. Suppose an agent repeatedly receives:

"Analyze this invoice and extract: vendor, total, tax and due date."

The high-level plan may be reusable:

1. Read invoice
2. Extract fields
3. Validate fields
4. Return structured result

Instead of asking the LLM to generate the same plan every time:

you can potentially cache stable plans.

9.2 Architecture#

9.3 Example#

async def get_plan(task):
    normalized = normalize_task(task)
    key = "plan:" + hashlib.sha256(normalized.encode()).hexdigest()

    cached = await redis_client.get(key)
    if cached:
        return json.loads(cached)

    plan = await planning_model(task)

    await redis_client.setex(key, 3600, json.dumps(plan))
    return plan

9.4 Important warning#

Reasoning plans are more sensitive than deterministic data. A cached plan may become invalid when:

• tools change
• permissions change
• available data changes
• system instructions change
• agent capabilities change

So include these versions in the cache key: task + agent version + toolset version + prompt version.

10. Task and job cache#

10.1 What is it?#

Long-running agents frequently run asynchronous jobs. For example:

The user might refresh the page. You don't want to start another job. Instead:

10.2 Idempotent task creation#

async def create_task(user_id, request):
    request_hash = hashlib.sha256(
        json.dumps(request, sort_keys=True).encode()
    ).hexdigest()
    key = f"task:{user_id}:{request_hash}"

    existing = await redis_client.get(key)
    if existing:
        return json.loads(existing)

    task = await start_agent_task(user_id, request)

    await redis_client.setex(key, 3600, json.dumps(task))
    return task

Now when a user clicks twice, the same request maps to the same task, instead of creating task 1 and task 2.

11. Idempotency cache#

11.1 Caching is not idempotency#

This deserves special attention. Consider POST /payments.

If the network times out, the client may retry, and the server receives payment request #1 and payment request #2. If both execute, the customer is charged ₹10,000 twice.

11.2 Idempotency key#

The client generates a key, for example idempotency_key = abc123, and sends it with the request. The server:

async def process_payment(idempotency_key, payment_data):
    cache_key = f"payment:{idempotency_key}"

    existing = await redis_client.get(cache_key)
    if existing:
        return json.loads(existing)

    result = await charge_payment(payment_data)

    await redis_client.set(cache_key, json.dumps(result), ex=86400)
    return result

Now retries become safe:

This is essential for agents that can trigger mutations.

12. Agent checkpoint cache#

12.1 What is it?#

Agent workflows can be extremely long. Consider:

1. Search
2. Download
3. Parse
4. Analyze
5. Compare
6. Validate
7. Generate report
8. Send email

If step 7 fails, restarting everything is wasteful. Checkpoint after important steps:

Then resume from the last checkpoint, straight into step 7.

12.2 Implementation#

async def checkpoint(task_id, step, state):
    key = f"checkpoint:{task_id}:{step}"
    await redis_client.set(key, json.dumps(state))


async def load_checkpoint(task_id, step):
    key = f"checkpoint:{task_id}:{step}"

    data = await redis_client.get(key)
    if not data:
        return None

    return json.loads(data)

13. Sub-agent result cache#

13.1 What is it?#

Modern agents can delegate tasks:

Suppose the research agent has already answered:

"Find the company's revenue for 2025."

The main agent shouldn't necessarily trigger another research agent for the exact same task.

13.2 Architecture#

13.3 Key design#

Key on tenant + sub-agent type + task + input + agent version. For example:

def subagent_key(tenant_id, agent_name, task, input_data, version):
    raw = json.dumps(
        {
            "tenant": tenant_id,
            "agent": agent_name,
            "task": task,
            "input": input_data,
            "version": version,
        },
        sort_keys=True,
    )
    return hashlib.sha256(raw.encode()).hexdigest()

14. Multi-agent shared cache#

14.1 What is it?#

Now consider several agents working together:

Agents may need to share results. For example:

The financial agent doesn't need to fetch the same information again.

14.2 But shared state introduces problems#

You need to define:

• Who can write?
• Who can read?
• Who owns the data?
• How long is it valid?
• What version produced it?
• Can another tenant access it?

For enterprise systems, this becomes an authorization problem. A safe key might include tenant ID + namespace + resource ID + version.

15. Long-running agent cache#

15.1 What is it?#

Some agents run for seconds, some for minutes and some for hours: deep research, data analysis, document processing, code generation, report generation, monitoring.

You don't want the agent's entire state to live only in memory. Instead, the worker loops:

If the worker dies, another one picks up where it stopped:

16. Designing a production agent cache#

16.1 Putting the pieces together#

At this point, we can combine the pieces:

16.2 Cache key design for agents#

Cache key design becomes extremely important once multiple agents and tools are involved.

• A weak key: "get_customer"
• A better key: tenant ID + tool name + arguments
• A production-oriented key: tenant ID + user scope + tool name + arguments + tool version + agent version + data version

For example:

def make_agent_cache_key(
    tenant_id,
    user_scope,
    component,
    input_data,
    component_version,
    data_version=None,
):
    payload = {
        "tenant_id": tenant_id,
        "user_scope": user_scope,
        "component": component,
        "input": input_data,
        "component_version": component_version,
        "data_version": data_version,
    }
    raw = json.dumps(payload, sort_keys=True)
    return hashlib.sha256(raw.encode()).hexdigest()

16.3 TTL strategy for agentic systems#

Different agent components need different TTLs:

These are examples, not universal values. The correct TTL depends on freshness requirements, data volatility, business impact, cost and failure-recovery requirements.

16.4 Cache invalidation in agentic systems#

This is where agent caching gets complicated. Suppose the agent reads a customer through a tool backed by a database:

In the database, the customer's status changes from ACTIVE to SUSPENDED. But the agent cache still says ACTIVE. Now the agent acts on stale information.

TTL-based#

Simple, but not always precise.

Event-based#

More accurate.

Version-based#

Keep a version on the record, for example customer_version = 42, and put it in the cache key: customer:123:v42. When the customer changes, customer_version becomes 43, and the old cache entry naturally becomes irrelevant.

Explicit invalidation#

await redis_client.delete(f"customer:{customer_id}")

Useful for important state changes.

16.5 Caching and agent safety#

Caching introduces a new attack surface. Consider:

If the cache isn't authorization-aware, User B sees data they may not be allowed to see. So the cache key should combine tenant + user permissions + resource + query + version.

16.6 Never cache sensitive results blindly#

Be particularly careful with:

• passwords
• authentication and access tokens
• payment information
• private customer information
• personal data
• healthcare information
• financial information
• secrets

Caching can turn a normal application bug into a cross-user data leak.

16.7 Cache stampede#

Another important production problem is the cache stampede. Imagine a popular cache entry expires:

You just destroyed the purpose of caching.

The fix is a lock, so only one worker refreshes the entry:

import asyncio
import json


async def get_with_lock(key, fetch_fn, ttl=300):
    cached = await redis_client.get(key)
    if cached:
        return json.loads(cached)

    lock_key = f"{key}:lock"
    acquired = await redis_client.set(lock_key, "1", nx=True, ex=30)

    if acquired:
        try:
            result = await fetch_fn()
            await redis_client.setex(key, ttl, json.dumps(result))
            return result
        finally:
            await redis_client.delete(lock_key)

    # Another worker is refreshing. Wait briefly and retry.
    await asyncio.sleep(0.1)
    return await get_with_lock(key, fetch_fn, ttl)

This prevents thousands of workers from performing the same expensive operation.

16.8 Cache observability#

Production agents need cache telemetry. At minimum, track cache hits, misses, errors, evictions, latency, size, stale reads and refresh count.

For agents, also track tool calls avoided, agent steps avoided, LLM calls avoided, API calls avoided, tokens saved, agent runtime saved and cost saved.

An agent cache dashboard might show:

17. Cache, state and idempotency#

17.1 Caching vs idempotency#

These concepts are related but different.

• Caching: "I already have the answer."
• Idempotency: "I already processed this operation."

GET customer is a good fit for caching. POST payment requires idempotency.

This distinction is extremely important when building agents that can take actions.

17.2 Caching vs state#

Another important distinction:

• Cache: temporary, reusable data, such as tool results, search results and API responses.
• State: information required to continue execution, such as the current task, completed steps, the agent plan, checkpoints and workflow status.

State may use the same infrastructure as a cache, such as Redis, but conceptually they are different. For critical state, you may want durable storage in addition to Redis:

17.3 A shared cache layer#

Instead of letting every component (tools, MCP, the agent, API clients) talk to Redis directly and implement caching differently, create a common abstraction:

import json


class Cache:
    def __init__(self, redis_client):
        self.redis = redis_client

    async def get(self, key):
        value = await self.redis.get(key)
        if value is None:
            return None
        return json.loads(value)

    async def set(self, key, value, ttl):
        await self.redis.setex(key, ttl, json.dumps(value))

    async def delete(self, key):
        await self.redis.delete(key)

Now cache = Cache(redis_client) can be shared across the agent, tool layer, MCP layer, workflow layer, API layer and memory layer.

17.4 Recommended agent cache architecture#

For a serious production system:

This gives you fast access, recovery, deduplication, lower cost, lower latency and better scalability.

18. Before you ship#

18.1 Production checklist#

Before deploying agent caching, ask:

Tool caching#

• Is this tool safe to cache?
• What is the TTL?
• Are arguments included in the key?
• Is the tool version included?
• Is tenant isolation enforced?

Agent state#

• Can the agent resume after failure?
• Are checkpoints persisted?
• Is state durable?
• Can two workers modify the same state?

MCP#

• Which tools are cacheable?
• Which resources are cacheable?
• Are resource versions tracked?
• Are permissions included?

APIs#

• Is the API response deterministic?
• Does the provider allow caching?
• What is the freshness requirement?
• What happens when the cache is stale?

Idempotency#

• Are mutations protected?
• Are retries safe?
• Is there an idempotency key?
• Can duplicate agent actions happen?

Operations#

• Cache hit and miss metrics?
• Cache latency?
• Cache size?
• Eviction policy?
• Stampede protection?
• Invalidation strategy?
• Security audit?

19. The full picture#

19.1 The core principle#

Agentic caching isn't about putting Redis between your agent and everything else. It's about identifying repeated work. An agent may repeatedly perform the same:

A production system should recognize "I have already done this" and safely reuse the result.

19.2 Part 2 takeaway#

The major caching layers for agentic AI are:

1. Tool result cache
2. Function call cache
3. Agent state cache
4. Workflow / step cache
5. MCP tool cache
6. MCP resource cache
7. API response cache
8. Agent memory cache
9. Planning / reasoning cache
10. Task / job cache
11. Idempotency cache
12. Agent checkpoint cache
13. Sub-agent result cache
14. Multi-agent shared cache
15. Long-running agent cache

The most important production distinction is:

And the overall architecture becomes:

The best agent isn't the one that calls the most tools. It's the one that knows when it doesn't need to call them again.

Next: Part 3, Conversational AI caching covers context, sessions, memory and responses.
