The AI Caching Playbook, Part 5: Cache the Agent's Work, Not Just the Answer

This is Part 5 of the AI Caching Playbook. The earlier parts looked at caching in LLM applications, agents, conversational systems and RAG pipelines.

But agentic AI introduces a much harder problem. A traditional RAG system might do:

An agent can do this:

The agent isn't performing one expensive operation. It is performing a sequence of operations, and every one of them can potentially be repeated.

That changes the caching problem completely.

1. The core problem with agentic AI#

1.1 One request, many steps#

Consider an agent that receives:

"Find the best laptop under ₹80,000, compare three options, check their current prices, and recommend one."

The agent might execute:

1. Understand the request
2. Create a plan
3. Search products
4. Search reviews
5. Fetch product details
6. Check prices
7. Compare specifications
8. Rank products
9. Generate a recommendation

Without caching, every request repeats everything. With caching, every request reuses previous work and executes only what changed:

The goal becomes:

Cache the work performed by the agent, not just the final response.

1.2 Agentic caching architecture#

A production agent can have caching at many levels:

Each layer has a different purpose.

2. Agent state cache#

2.1 What is it?#

The first thing to cache is the agent's current state. For example:

{
  "goal": "Find the best laptop",
  "status": "researching",
  "current_step": 3,
  "products_found": 12,
  "selected_products": 5
}

Instead of reconstructing this state from the entire conversation every time (conversation → LLM → infer the current state), store it explicitly and give the agent both:

2.2 Redis implementation#

import json

import redis

r = redis.Redis(host="localhost", port=6379, decode_responses=True)


def state_key(tenant_id, user_id, session_id):
    return f"agent:state:{tenant_id}:{user_id}:{session_id}"


def save_agent_state(tenant_id, user_id, session_id, state):
    key = state_key(tenant_id, user_id, session_id)
    r.setex(key, 3600, json.dumps(state))


def get_agent_state(tenant_id, user_id, session_id):
    key = state_key(tenant_id, user_id, session_id)

    value = r.get(key)
    if not value:
        return None

    return json.loads(value)

This gives the agent a durable working state.

2.3 Why explicit state matters#

Without explicit state, when the agent asks itself "What have I already checked?", the LLM has to reconstruct the answer from context.

With explicit state, the agent already knows:

state.current_step = 4
state.completed_tools = [...]
state.results = [...]

This reduces tokens, latency, repeated reasoning, context size and cost. A useful principle:

Don't make the LLM remember state that your application can represent deterministically.

3. Planning cache#

3.1 What is it?#

Agents often generate plans. For the goal "Research three laptops", the plan might be:

1. Search products
2. Get specifications
3. Get prices
4. Compare
5. Recommend

Generating the plan may itself require an LLM call. If the same type of task appears repeatedly, the plan can sometimes be cached, keyed on goal + agent type + planning prompt version + model version.

3.2 Cache key#

import hashlib
import json


def planning_cache_key(goal, agent_type, model_version, prompt_version):
    payload = {
        "goal": " ".join(goal.lower().split()),
        "agent_type": agent_type,
        "model": model_version,
        "prompt": prompt_version,
    }
    digest = hashlib.sha256(json.dumps(payload, sort_keys=True).encode()).hexdigest()
    return f"agent:plan:{digest}"

Then:

def get_or_create_plan(goal, agent_type, planner):
    key = planning_cache_key(goal, agent_type, "model-v3", "prompt-v4")

    cached = r.get(key)
    if cached:
        return json.loads(cached)

    plan = planner.create_plan(goal)

    r.setex(key, 1800, json.dumps(plan))
    return plan

3.3 But don't cache every plan#

Planning is context-sensitive. "Book a flight to Chennai" can depend on the current date, budget, user preferences, passport requirements and available flights.

So plan caching is safest when:

• the task is deterministic
• the plan doesn't depend on volatile state
• the environment hasn't changed
• the same tool set is available

For dynamic agents, cache reusable plan templates rather than blindly reusing complete plans. For example, a research task always follows the same shape, while the individual values stay dynamic:

4. Tool result cache#

4.1 What is it?#

This is one of the most valuable caches in agentic systems. Suppose an agent calls:

weather_tool(city="Bangalore")

and receives:

{
  "temperature": 27,
  "condition": "Cloudy"
}

If another request asks for Bangalore's weather 30 seconds later, you may not need another external API call:

4.2 A generic tool cache#

Instead of implementing caching separately for every tool, create a wrapper:

import hashlib
import json


def tool_cache_key(tool_name, arguments, tool_version):
    payload = {
        "tool": tool_name,
        "version": tool_version,
        "arguments": arguments,
    }
    digest = hashlib.sha256(json.dumps(payload, sort_keys=True).encode()).hexdigest()
    return f"agent:tool:{digest}"

Now:

def cached_tool_call(tool_name, arguments, tool_version, tool_function, ttl=300):
    key = tool_cache_key(tool_name, arguments, tool_version)

    cached = r.get(key)
    if cached:
        return json.loads(cached)

    result = tool_function(**arguments)

    r.setex(key, ttl, json.dumps(result))
    return result

This creates a reusable tool caching layer.

4.3 Deterministic vs non-deterministic tools#

Not every tool should be cached the same way:

The last group are side-effecting operations. Caching them can be dangerous.

4.4 Read tools vs write tools#

A useful production classification:

You should not run cache.get(key) before a write operation and assume that prevents duplicate execution. Instead, use an idempotency key + an execution record + transaction semantics.

5. API response cache#

5.1 What is it?#

Agents frequently call APIs: weather, search, maps, CRM. Every external API call adds latency, cost, rate-limit pressure and failure risk. A generic API cache can help:

def api_cache_key(service, endpoint, params, version="v1"):
    payload = {
        "service": service,
        "endpoint": endpoint,
        "params": params,
        "version": version,
    }
    digest = hashlib.sha256(json.dumps(payload, sort_keys=True).encode()).hexdigest()
    return f"api:{digest}"

Then:

def cached_api_request(service, endpoint, params, request_function, ttl=60):
    key = api_cache_key(service, endpoint, params)

    cached = r.get(key)
    if cached:
        return json.loads(cached)

    response = request_function(endpoint, params)

    r.setex(key, ttl, json.dumps(response))
    return response

6. Database query cache#

6.1 What is it?#

Agents may also query databases repeatedly (agent → SQL → database → result). A safe, read-only query can sometimes be cached:

def db_query_cache_key(database, query, parameters, schema_version):
    payload = {
        "database": database,
        "query": query,
        "parameters": parameters,
        "schema": schema_version,
    }
    digest = hashlib.sha256(json.dumps(payload, sort_keys=True).encode()).hexdigest()
    return f"db:query:{digest}"

Then:

def cached_query(query, parameters, execute, ttl=30):
    key = db_query_cache_key("production", query, parameters, "schema-v8")

    cached = r.get(key)
    if cached:
        return json.loads(cached)

    result = execute(query, parameters)

    r.setex(key, ttl, json.dumps(result))
    return result

But database caching needs a careful invalidation strategy. After an UPDATE customer, the related query cache may be stale.

6.2 Cache database results by data version#

A stronger approach is to keep a data version, for example customer_data_version = 481. When the relevant data changes, the version moves from 481 to 482, and because the version is part of the key (query + data version), the cache key changes with it.

This is often easier to reason about than trying to find every query affected by an update.

7. Function result cache#

7.1 What is it?#

Not every agent tool calls an external API. You may have expensive internal functions such as calculate_risk(), calculate_shipping(), generate_report(), classify_document() and score_customer(). These can be cached too:

def cached_function(function_name, function_version, arguments, function, ttl=600):
    key = tool_cache_key(function_name, arguments, function_version)

    cached = r.get(key)
    if cached:
        return json.loads(cached)

    result = function(**arguments)

    r.setex(key, ttl, json.dumps(result))
    return result

This turns caching into an infrastructure capability rather than an application-specific feature.

8. Agent trajectory cache#

8.1 What is it?#

An agent's execution can be represented as a trajectory:

We can store this trajectory. For example:

{
  "goal": "Research product",
  "steps": [
    { "tool": "search", "input": "product A", "output": "..." },
    { "tool": "pricing", "input": "product A", "output": "..." }
  ]
}

This is useful for debugging, replay, evaluation, recovery, auditing and optimization.

But trajectory reuse must be handled carefully. A previous trajectory is not automatically valid in a new environment.

8.2 Reusing agent trajectories#

Suppose an agent repeatedly receives:

"Generate our weekly sales report."

The workflow may be:

1. Query the sales DB
2. Query the returns DB
3. Calculate metrics
4. Generate a chart
5. Summarize

Instead of letting the LLM rediscover this workflow every time, map the goal to the known workflow and run it on the current data:

This is much more reliable. Notice what we're caching: the workflow, not the old data. That's an important distinction.

9. Workflow step and partial execution cache#

9.1 Workflow step cache#

A better abstraction is to cache individual workflow steps. For the weekly report, if only step 1's input changes:

This is much better than rerunning the entire agent.

9.2 Partial execution cache#

This is one of the most powerful concepts in agentic caching. Suppose a task runs steps A → B → C → D → E, and execution fails at D.

This can save enormous amounts of computation.

10. Agent checkpointing#

10.1 Implementation#

Store the execution state after important steps:

def checkpoint_key(execution_id, step_id):
    return f"agent:checkpoint:{execution_id}:{step_id}"


def save_checkpoint(execution_id, step_id, state):
    key = checkpoint_key(execution_id, step_id)
    r.set(key, json.dumps(state))


def load_checkpoint(execution_id, step_id):
    key = checkpoint_key(execution_id, step_id)

    value = r.get(key)
    if not value:
        return None

    return json.loads(value)

Now a long-running agent can resume execution.

10.2 Checkpoint vs cache#

These are related but not identical:

A production agent often needs both.

11. Agent context cache#

11.1 What is it?#

Agent context can become enormous: the system prompt, the conversation, the plan, tool outputs, RAG results and previous reasoning state. Instead of reconstructing everything, maintain structured context:

agent_context = {
    "goal": "...",
    "plan": [...],
    "state": {...},
    "tool_results": {...},
    "retrieved_docs": [...],
    "recent_events": [...],
}

Then cache the context object:

def agent_context_key(session_id, context_version):
    return f"agent:context:{session_id}:{context_version}"

11.2 Context versioning#

Suppose the agent context is at version 12. After a tool result arrives it becomes version 13, and after another tool call, version 14:

The cache key becomes agent:context:session123:v14. This is safer than mutating a single cache entry without tracking versions.

12. Agent memory cache#

12.1 Short-term state and long-term memory#

Long-running agents may have user preferences, past tasks, important facts, previous outcomes and learned patterns. Store durable memory separately from short-term execution state:

Don't treat all memory as the same thing:

Caching can speed up access to long-term memory without making Redis the source of truth.

13. Semantic tool cache#

13.1 What is it?#

Exact tool caching handles search("latest AI news"). A semantic tool cache might also treat "recent AI news" as the same request.

However, this should only be used when semantic equivalence is safe. For a search tool, "What happened in AI today?" and "What happened in AI yesterday?" are semantically close but need different results.

So semantic tool caching needs semantic similarity + time constraints + tool semantics + freshness.

14. Cache-aware tools#

14.1 Cache-aware tool design#

A powerful production pattern is to make tools explicitly cache-aware. Instead of exposing only search(query), define search(query, cache_policy), for example:

cache_policy = {
    "enabled": True,
    "ttl": 300,
    "scope": "tenant",
    "freshness": "5m",
}

The agent runtime can then apply consistent caching rules.

14.2 Tool metadata should describe cacheability#

A tool registry could contain:

tools = {
    "weather": {
        "cacheable": True,
        "ttl": 300,
        "side_effect": False,
    },
    "get_customer": {
        "cacheable": True,
        "ttl": 30,
        "side_effect": False,
    },
    "send_email": {
        "cacheable": False,
        "side_effect": True,
    },
}

Now the agent runtime knows how to treat each tool. This is much safer than letting every agent developer invent their own rules.

15. Side effects: idempotency and retries#

15.1 Idempotency for write tools#

Caching isn't enough for side-effecting operations. Suppose the agent calls send_email() and the request times out. The agent doesn't know whether the email was sent, so it retries, and two emails may go out.

The right solution is often idempotency, not caching:

idempotency_key = f"{execution_id}:{tool_name}:{step_id}"

The server stores the idempotency key with the execution result. Retries then return the original result instead of executing the operation again.

15.2 Retry and cache interaction#

When a tool call hits an API timeout, before retrying the system should determine whether the operation was:

• read-only
• partially completed
• side-effecting
• idempotent

For reads, a plain retry is usually straightforward. For writes, retry + idempotency is much safer.

16. Multi-agent cache sharing#

16.1 Sharing work between agents#

Now imagine a supervisor with three agents that all need the same information:

Without shared caching, each agent calls the API itself. With a shared tool cache, the first call is reused by the others. This can significantly reduce duplicated work.

But shared caches need strict scope.

16.2 What can be shared across agents?#

The cache scope should be explicit: global, tenant, team, user, session or execution.

17. Agent response cache#

17.1 What is it?#

At the top level, we can still cache final responses. But the response cache key should include the agent's important dependencies:

def agent_response_key(
    tenant_id,
    user_scope,
    task,
    agent_version,
    toolset_version,
    context_version,
):
    payload = {
        "tenant": tenant_id,
        "scope": user_scope,
        "task": task,
        "agent": agent_version,
        "tools": toolset_version,
        "context": context_version,
    }
    digest = hashlib.sha256(json.dumps(payload, sort_keys=True).encode()).hexdigest()
    return f"agent:response:{digest}"

17.2 Why agent response caching is harder#

An agent response can depend on the user, the time, tools, external APIs, the database, memory, RAG, the agent version, tool versions and execution state. So for agents especially:

Same prompt ≠ same answer.

"What's the weather?" should almost never have a long-lived response cache. But "What are the steps in our internal onboarding process?" may be highly cacheable.

18. Dependencies, versions and invalidation#

18.1 The agent cache dependency graph#

A production agent can have a dependency graph like:

If Tool B's result changes, everything downstream of it may need recomputing:

This is why dependency tracking becomes more important as agents become more complex.

18.2 Cache invalidation in agents#

There is no universal TTL that solves agent caching. Instead, ask:

What caused this result to become invalid?

These versions can be part of cache keys.

18.3 Version everything important#

A useful production pattern is to version the agent, prompts, tools, workflows, knowledge, schema and data. Then:

cache key = input + agent version + prompt version + tool version + data version

Changing a version naturally creates a new cache namespace.

19. Long-running agents and recovery#

19.1 Long-running agents#

Some agents don't finish in seconds. Research agents, data analysis agents, report generators, software engineering agents and workflow automation agents may run for minutes or hours.

For them, caching is less about response reuse and more about execution recovery. This is where checkpoints become critical.

19.2 Production agent execution#

Instead of:

result = run_agent(task)

think:

execution = start_execution(task)

while not execution.complete:
    step = execution.next_step()
    result = execute_step(step)

    save_checkpoint(execution.id, step.id, execution.state)

Now if the process crashes, it restarts, loads the checkpoint and resumes, rather than starting from zero.

19.3 Failure recovery#

Imagine steps 1–3 succeeded, step 4 failed and step 5 never started. Recovery should look like:

not a rerun of steps 1 through 5. This is one of the biggest benefits of caching intermediate execution state.

20. Agent caching meets RAG caching#

20.1 Agentic RAG#

Agentic RAG combines both systems:

Now caching happens across several dimensions:

This is where a unified cache architecture becomes valuable.

21. A shared agent cache layer#

21.1 A generic agent cache wrapper#

We can create one reusable abstraction:

import json


class AgentCache:
    def __init__(self, redis_client):
        self.redis = redis_client

    def get(self, key):
        value = self.redis.get(key)
        if not value:
            return None
        return json.loads(value)

    def set(self, key, value, ttl):
        self.redis.setex(key, ttl, json.dumps(value))

    def get_or_compute(self, key, compute, ttl=300):
        cached = self.get(key)
        if cached is not None:
            return cached

        result = compute()
        self.set(key, result, ttl)
        return result

Usage:

cache = AgentCache(r)

result = cache.get_or_compute(
    key="agent:tool:weather:bangalore",
    compute=lambda: weather_tool("Bangalore"),
    ttl=300,
)

This creates a consistent caching interface across the agent runtime.

21.2 Add a cache policy#

A more production-ready version accepts a policy:

cache_policy = {
    "enabled": True,
    "ttl": 300,
    "scope": "tenant",
    "stale_while_revalidate": True,
    "semantic": False,
}

The runtime can then decide:

• Should I cache?
• For how long?
• Who can reuse it?
• Can stale data be returned?
• Can semantic matching be used?

This moves caching from ad-hoc code into an explicit system design.

22. Observability#

22.1 Observability for agent caching#

Traditional cache metrics aren't enough. Track agent.cache.hit, agent.cache.miss, agent.cache.stale and agent.cache.lock_wait, but also:

• agent.tool.calls_avoided
• agent.llm.calls_avoided
• agent.steps_reused
• agent.steps_recomputed
• agent.tokens_saved
• agent.execution_time_saved
• agent.cost_saved

For example:

metrics.increment("agent.tool.cache_hit", tags={"tool": tool_name})
metrics.increment("agent.execution.step_reused")

22.2 Measure agent-level savings#

Suppose a typical agent run looks like this before and after caching:

The important metric isn't just "cache hit rate = 70%". The real business metrics are cost, from $0.40 to $0.12, and latency, from 25 s to 9 s. That's what matters.

22.3 Don't optimize for cache hit rate alone#

A 99% hit rate can still be bad. A 99% hit rate on a cheap operation may be worth far less than a 10% hit rate on an expensive LLM operation.

A better metric:

Cache value = avoided computation cost × reuse frequency × correctness confidence

23. Security and scope#

23.1 Security considerations#

Agent caching introduces significant security risks. Never accidentally share:

• user secrets
• API responses
• private documents
• authorization-sensitive results
• customer records
• tool credentials
• private agent memory

And never cache credentials (API keys, passwords, OAuth tokens, session tokens) as if they were normal tool results.

23.2 Cache scope#

Every cache should answer:

Who is allowed to reuse this result?

The possible scopes are global, tenant, team, user, session and execution. For example:

This makes cache boundaries explicit.

24. Before you ship#

24.1 Production agent caching checklist#

State#

• Agent state is explicit
• Session state is cached
• Execution state is versioned
• Checkpoints exist for long-running tasks

Planning#

• Planning cache evaluated
• Agent version included
• Prompt version included
• Dynamic plans aren't blindly reused

Tools#

• Tools classified as read or write
• Cacheability defined
• TTL defined per tool
• Tool version included

APIs#

• API response caching evaluated
• Freshness requirements defined
• Rate limits considered
• Errors aren't cached blindly

Databases#

• Read queries cached where appropriate
• Data versioning considered
• Mutation invalidation defined

Execution#

• Workflow steps are independently cacheable
• Partial results can be reused
• Checkpointing implemented
• Failed executions can resume

Multi-agent#

• Shared cache boundaries defined
• Tenant isolation enforced
• User-specific results protected

Security#

• Authorization scope included
• Sensitive data protected
• Credentials never cached as ordinary results
• Cache access monitored

Observability#

• Hit rate
• Miss rate
• Steps reused
• Tool calls avoided
• LLM calls avoided
• Tokens saved
• Cost saved
• Latency saved

25. The full picture#

25.1 The complete agentic cache architecture#

Putting everything together:

25.2 The big shift in thinking#

Traditional caching asks:

"Can I cache the response?"

RAG caching asks:

"Can I cache the retrieval?"

Agentic caching asks a much bigger question:

"Which parts of the agent's work can I safely reuse?"

That could be the plan, a tool call, an API result, a database result, a search result, an embedding, a reranking, an intermediate calculation, a workflow step, agent state, agent memory, context, a checkpoint or the final response.

The agent doesn't always need to start from zero.

25.3 The production principle#

A naive agent does everything on every request:

A production agent does this instead:

That's the real value of agentic caching.

Don't cache just the answer. Cache the work that produced the answer.

25.4 The final mental model#

Think of an agent execution as a computation graph:

Each node is potentially a cacheable computation:

That is how caching evolves from a simple optimization into an execution architecture.

25.5 Part 5 core takeaways#

If you remember only ten things:

1. Cache agent state.
2. Cache deterministic tool results.
3. Separate read tools from write tools.
4. Use idempotency for side effects.
5. Cache workflow steps, not only final responses.
6. Checkpoint long-running executions.
7. Version agents, prompts, tools and data.
8. Make cache scope explicit.
9. Track work avoided, not just cache hits.
10. Design agents to reuse previous computation.

The ultimate goal is simple:

A production agent should not redo work that is still valid.

And that leads to the next level of the caching architecture.

What's next?#

Part 6: LLM inference caching#

We've now covered caching around the application: conversation, RAG, agents and tools. But there is another layer where enormous amounts of computation happen, inside the model:

Part 6 will go deeper into:

• KV cache, prefix cache, prompt caching and prefill caching
• decode-time caching, attention KV reuse and session-level KV reuse
• prefix matching, cache-friendly prompt design, and static vs dynamic prompt sections
• long-context caching, multi-turn KV reuse and batch inference caching
• speculative decoding and continuous batching
• GPU memory constraints, KV cache quantization and KV cache eviction
• paged attention and prefix sharing
• inference cost optimization, latency vs memory trade-offs, and production LLM serving architecture

The central question becomes:

What if we could avoid making the model recompute the same attention work every time?

That takes us from application-level caching into the internals of LLM inference itself.

Next: Part 6, LLM inference caching covers the KV cache, prefix caching and prompt caching inside the model.
